SCM Class PX 350I

Description

The SCM Class PX 250I delivers optimal finishing quality with its rigid saw unit, ensuring effortless and precise cutting of veneered or solid wood panels at 90° or tilted up to 46°. Its “Ready” mobile control panel enables simple, rapid programmed movements, while the double powered and programmed rear stop provides immediate and accurate workpiece positioning. A sturdy telescopic squaring fence with a tilted metric scale and two reversible stops supports panel squaring up to 2500 × 3000 mm, or up to 3200 × 3200 mm with the optional upgrade. Combined with a large fixed table that ensures stable support during machining, the Class PX 250I offers reliability, accuracy, and efficiency for demanding cutting operations.

class px 350i
maximum squaring stroke mm 2600 3200 3800
blade tilting mm 0÷46°
maximum saw blade diameter (cutting) mm 350
maximum saw blade diameter (engraving + cutting) mm 300
max. saw blade projection (D350) from table at 90°/45° mm 105/72
max. saw blade projection (D300) from table at 90°/45° mm 80/50
blade rotation speed RPM 4000
cutting width on rear fence mm 1300
Other technical features:
three-phase motor 7 kW 50 Hz
exhaust hoods diameter mm 120 (1) - 100 (2)
overall dimensions (LxWxH) mm 3859x3196x1368 4459x3196x1368 5059x3196x1368
